Name: Eagle (discontinued product)
Brand: RKI Instruments

Suggested Alternative Products

Features		Eagle	GX-6000	GX-8000	SC-8000
Sensor Capacity		6	6	5	1 toxic
Sample Range		125 feet	50 feet	100 feet	100 feet
Combustible Ranges	PPM Leak Check	•	•
	% LEL	•	•	•
	% Volume	•	•	•
Battery Life		18 hrs Ni-Cd 30 hrs Alkaline size D	14 hrs Li-ion 8 hrs Alkaline size AA	12 hrs Li-ion 6 hrs Alkaline size AA	25 hrs Li-ion 18 hrs Alkaline size AA
Warranty		2 years	2 years	1 year	1 year
Modes			Leak Check & Bar Hole
Inert Mode	Combustibles	•	•
Inert Mode	Oxygen	•	•
High Range H2S		1,000 ppm		1,000 ppm (RX-8000)
PID (Photoionization)			•
Toxic Gases	Ammonia (NH3)	75.0 ppm	400 ppm		75.0 ppm
	Arsine (AsH3)	0.20 ppm			0.20 ppm
	Bromine (Br2)	1.00 ppm			1.00 ppm
	Carbon Dioxide (CO2)	5K, 10K ppm 5, 20, 60% vol.	10K ppm 10% volume
	Carbon Monoxide (CO)	500 ppm	500 ppm	500 ppm	300 ppm
	Chlorine (Cl2)	3.00 ppm	10.0 ppm		3.00 ppm
	Chlorine Trifluoride (CLF3)	1.00 ppm			1.00 ppm
	Diborane (B2H6)	0.30 ppm			0.30 ppm
	Fluorine (F2)	5.00 ppm			3.00 ppm
	Germane (GeH4)	0.20 ppm			0.80 ppm
	Hydrogen Bromide (HBr)	6.00 ppm			6.00 ppm
	Hydrogen Chloride (HCl)	15.00 ppm			15.0 ppm
	Hydrogen Cyanide (HCN)	0.4-30 ppm	15.0 ppm		15.0 ppm
	Hydrogen Fluoride (HF)	0.4-9.0 ppm			0.4-9.0 ppm
	Hydrogen Iodide (HI)	5.00 ppm			5.00 ppm
	Hydrogen Peroxide (H2O2)	3.00 ppm			3.00 ppm
	Hydrogen Selenide (H2Se)	0.20 ppm			0.20 ppm
	Hydrogen Sulfide (H2S)	100 ppm	100 ppm	100 ppm	30.0 ppm
	Nitrogen Dioxide (NO2)	15.0 ppm	20.0 ppm		15.0 ppm
	Nitric Oxide (NO)	100 ppm			100 ppm
	Ozone (O3)	1.00 ppm			1.00 ppm
	Phosphine (PH3)	1.00 ppm	20.0 ppm		1.00 ppm
	Phosphorus Trifluoride (PF3)				10.0 ppm
	Silane (SiH4)	15.0 ppm			15.0 ppm
	Sulfur Dioxide (SO2)	6.00 ppm	99.90 ppm		6.00 ppm

Overview

The Eagle is the most versatile portable gas detector on the market. Equipped with features that are not available on most competitive units, the EAGLE is a powerful instrument that does more than just offer the standard confined space protection for LEL, O2, H2S and CO. Detection combinations never before offered in a portable gas monitor are now available featuring the industry’s widest selection of high quality, long life and field proven sensors.

Vaporized hydrogen peroxide gas detection (VHP) in fumigation disinfection of medical facilities, pharmaceutical environments, including cleanrooms, production filling lines, and chemical fogging for the food industry.

Unique EAGLE features include PPM or LEL hydrocarbon detection at the push of a button; infrared sensors for CO2, methane or hydrocarbons in LEL and % volume ranges; a methane elimination switch for environmental applications, a long list of super toxic gases and measurable ranges, and dual hydrophobic filters that increases its water resistant performance. The EAGLE has a strong internal pump with a low flow auto shut off and alarm, which can draw samples from up to 125 feet even with the dual hydrophobic filters in place. This allows for quick response and recovery from distant sampling locations. The EAGLE will continuously operate for over 30 hours on alkaline batteries or 18 hours on Ni-Cads. A variety of accessories are also available to help satisfy almost any application such as long sample hoses, special float probes for tank testing, continuous operation adapters, remote alarms and strobes, and dilution fittings, just to name a few.

Specifications

Enclosure	Weather resistant, chemical resistant, RF/EMI coated high impact polycarbonate polyester blend. Can be set in rain or into 2.5 inches of water without damage. Ergonomically balanced with rugged top mounted handle.
Dimensions	10.5″ long x 5.9″ x 7″ tall
Weight	5 lbs.
Detection Principle	Catalytic combustion, electrochemical cell, galvanic cell, and infrared.
Sensor Life	2 years under normal conditions.
Sampling Method	Powerful, long-life pump (over 6,000 hours) can draw samples over 125 feet. Flow rate approximately 2.0 SCFH.
Display	4 x 20 LCD readout with backlighting. Viewed through window in case top. Displays readings & status of all channels simultaneously.
Alarms	2 alarms per channel plus TWA and STEL alarms. Fully adjustable for levels, latching or self reset and silenceable.
Alarm Method	Buzzer 85dB at 30 cm, dual high intensity LED’s, and blinking display.
Controls	6 external push buttons for operation, demand zero, and autocalibration. Buttons also access LEL/ppm, alarm silence, peak hold, TWA /STEL values, battery status and many other features.
Continuous Operating Hours	30 hours minimum using alkaline batteries, or 18 hours using Ni-Cads.
Power Source	Size D batteries, 4 alkaline or Ni-Cad. Charger has alkaline recognition to prevent battery damage if alkalines are charged.
Operating Temp. & Humidity	-10°C to 40°C (14°F to 104°F), 0 to 95% RH, non-condensing.
Indication Accuracy	Maximum variance +/- 5% of full scale.
Response Time	30 seconds to 90% (for most gases).
Safety Design	Intrinsically Safe, Class I, Division 1, Groups A, B, C and D. CSA / NRTL & UL Classified (most versions).
Standard Accessories	Shoulder strap, alkaline batteries, hydrophobic probe, and 5 foot hose (for special toxic gas versions, shorter teflon hose used without probe).
Optional Accessories	• Remote alarm • Dilution fitting (50/50) • Ni-Cad batteries • Battery charger, 115 VAC, 220 VAC, or 12 VDC • Continuous operation adapter, 115 VAC or 12 VDC • Extra loud buzzer • Extension probes • External hydrophobic filter
Warranty	One year material and workmanship

Gases

Standard Confined Space Gases
Gas	Measuring Range	Accuracy * Which ever is greater
Hydrocarbons (CH4, std)	0 – 100% LEL	± 5% of reading or ± 2% LEL (*)
Hydrocarbons (CH4, std)	0 – 50,000 ppm	± 50 ppm or ± 10% of reading (*)
Oxygen (O2)	0 – 40% Vol.	± 0.5% O2
Carbon Monoxide (CO)	0 – 500 ppm	± 5% of reading or ± 5 ppm CO (*)
Hydrogen Sulfide (H2S)	0 – 100 ppm	± 5% of reading or ± 2 ppm H2S (*)
Super Toxics and Other Gases
Ammonia (NH3)	0 – 75 ppm	± 10% of reading or ± 5% of full scale (*)
Arsine (AsH3)	0 – 1 ppm, 0 – 200 ppb
Chlorine (Cl2)	0 – 3 ppm
Chlorine Dioxide (ClO2)	0 – 1 ppm
Fluorine (F2)	0 – 3 ppm
Hydrogen Fluoride (HF)	0.4 – 9 ppm
Hydrogen Chloride (HCl)	0 – 15 ppm
Hydrogen Cyanide (HCN)	0.4 – 30 ppm
Hydrogen Peroxide (H2O2)	0 – 3 ppm
Hydrogen Selenide (H2Se)	0 – 0.2 ppm
Hydrogen Sulfide (H2S)	0 – 1 ppm, 0 – 30 ppm
Nitrogen Dioxide (NO2)	0 – 15 ppm
Ozone (O3)	0 – 1 ppm
Nitric Oxide (NO)	0 – 100 ppm
Phosphine (PH3)	0 – 1 ppm
Silane (SiH4)	0 – 15 ppm
Sulfur Dioxide (SO2)	0 – 6 ppm
IR Sensors
Carbon Dioxide (CO2) (IR Sensor)	0 – 5,000 ppm, 0 – 10,000 ppm, 0 – 5% Vol. 0 – 20% Vol. 0 – 60% Vol.	± 5% of reading or ± 2% of full scale (*)
Methane (CH4) (IR Sensor)	0 – 100% LEL, 0 – 100% Vol.
Isobutane (iC4H10) (IR Sensor)	0 – 100% LEL, 0 – 30% Vol.
